Line Interacitve UPS

LED display or LCD display selectable

Microprocessor-based digital control

Boost and buck AVR for voltage stabilization

Auto sensing frequency

Wide input voltage range

Power-on self test

Cold start

Auto restart when mains power is restored

Auto track mains phase to ensure that inverter output voltage has same phase with utility voltage, reducing transfer time and peak surge

Intelligent battery management: battery temperature compensation to extend the battery life; three-stage charging to shorten recharge time

Short circuit, battery overcharge / overdischarge, overload, surge protections

Automatic charging in OFF mode

Optional no-load shutdown

Optional RS232 / USB communication port and RJ11 / RJ45 protection

Unattended safety shutdown: system alarm and auto Power-On / Off by RS232 or USB interface communicating with PC

EA200 400 - 3000VA

MODEL

EA240

EA260

EA280

EA2120

EA2150

EA2200

EA2300

Capacity

400 VA / 240 W

600 VA / 360 W

800 VA / 480 W

1200 VA / 720 W

1500 VA / 900 W

2000 VA / 1200 W

3000 VA / 1800 W

INPUT

Voltage

100 / 110 / 120 V: 80 ~ 150 Vac; 220 / 230 / 240 V: 162 ~ 295 Vac (145 ~ 295 Vac optional)

Frequency

50 / 60 Hz ± 10% (auto-sensing)

OUTPUT

Voltage

100 / 110 / 120 Vac ± 10% or 220 / 230 / 240 Vac ± 10%

Frequency

50 / 60 Hz ± 1% (auto-sensing)

Waveform

Mains mode: pure sine wave; Battery mode: simulated sine wave

Transfer time

Typical 8 ms, 10 ms max.

BATTERIES

DC voltage

12 V

24 V

48V

Configuration

12 V / 4.5 Ah × 1

12 V / 7.0 Ah × 1

12 V / 8.0 Ah × 1

12 V / 7.0 Ah × 2

12 V / 8.0 Ah × 2

12 V / 9.0 Ah × 2

12 V / 9.0 Ah × 4

Recharge time

6 ~ 8 h

OTHERS

Protections

Short circuit - battery overcharge – overdischarge – overload - surge

Communications

USB / RS232 (optional)

Humidity

20 ~ 90% RH @ 0 ~ 40℃ (non-condensing)

Noise level

≤ 45 dB (1 m)

Plastic
case

Net / Gross weight (kg)

3.7 / 4.0

4.3 / 4.6

5.2 / 5.5

8.6 / 9.0

10.1 / 10.5

/

Dimensions
(W × D × H) (mm)

100 × 290 × 140

140 × 345 × 170

/

Packaged dimensions
(W × D × H) (mm)

139 × 335 × 210

198 × 406 × 245

/

Quantity / 20 ft

2300 pcs

1000 pcs

/

Metal
case

Net / Gross weight (kg)

/

4.3 / 4.7

5.2 / 5.6

9.6 / 10.1

11.3 / 11.7

12.9 / 13.3

19.3 / 20.6

Dimensions
(W × D × H) (mm)

/

95 × 320 × 160

125 × 320 × 225

125 × 380 × 225

157.5 × 452 × 211

Packaged dimensions
(W × D × H) (mm)

/

145 × 375 × 230

180 × 390 × 295

180 × 450 × 295

238 × 536 × 295

Quantity / 21 ft

/

2000 pcs

1000 pcs

658 pcs

l All specifications are subject to change without notice.
l Custom-made specifications are acceptable.
